LT119A/LT319A LM119/LM319 Dual Comparator FEATURESDESCRIPTION n Guaranteed Maximum 0.5mV Input Offset Voltage The LT®119A is an improved version of the LM119 dual n Input Protection Diodes comparator. It features lower input offset voltage and n Operates From Single 5V Supply offset current, higher voltage gain, guaranteed common n 25mA Drive Capability mode rejection and input protection diodes. n 80ns Response Time The LT119A is capable of operation over a supply range from 5V to ±15V and can drive 25mA loads from each APPLICATIONS open collector output. A separate ground pin allows the LT119A to isolate system grounds. n Window Detectors n Linear Technology Corporation’s advanced processing, High Speed One Shot n design techniques and reliability make the LT119A/LT319A Relay/Lamp Drivers n an ideal choice over previous devices in most comparator Voltage Controlled Oscillators applications. L, LT, LTC, LTM, Linear Technology and the Linear logo are registered trademarks of Linear Technology Corporation. All other trademarks are the property of their respective owners. TYPICAL APPLICATIONWindow Detector*Response Time For Various Input Overdrives 5V 6 5 VUT + 3 10 500Ω 4 2mV 1 1/2 LT319A TTL OUTPUT 3 20mV 5mV V OUTPUT IN – 4 2 VOLTAGE (V) 2 1 VOUT = 5V FOR 0 VS = ±15V 8 R + VLT ≤ VIN ≤ VUT 100 L = 500Ω VOUT = 0V FOR V++ = 5V 6 INPUT 50 1/2 LT319A VIN ≤ VLT OR VIN ≤ VUT TA = 25°C 9 VOLTAGE (mV) V 0 LT – 7 5 0 50 100 150 200 250 300 350 TIME (ns) LT119/319 TA2 LT119/319 TA1 *ALLOWED WINDOW FOR SINGLE 5V SUPPLY IS 1.2V TO 3.8V 119a319afc 1 Document Outline Features Applications Description Typical Application Absolute Maximum Ratings Pin Configuration Order Information Electrical Characteristics Typical Performance Characteristics Typical Applications Schematic Diagram Package Description Revision History Typical Application
