SN74HCS05 www.ti.com
SCLS797A – JUNE 2020 – REVISED OCTOBER 2020
SN74HCS05
SCLS797A – JUNE 2020 – REVISED OCTOBER 2020
SN74HCS05 Hex Inverter with Open-Drain Outputs and Schmitt-Trigger Inputs 1 Features 2 Applications
• Wide operating voltage range: 2 V to 6 V • Drive indicator LEDs • Schmitt-trigger inputs allow for slow or noisy input • Level-shift using open-drain outputs signals • Invert a digital signal • Low power consumption
3 Description
– Typical ICC of 100 nA – Typical input leakage current of ±100 nA This device contains six independent inverter with • ±7.8-mA output drive at 5 V open-drain outputs and Schmitt-trigger inputs. Each gate performs the Boolean function Y = A in positive • Extended ambient temperature range: –40°C to logic. +125°C, TA
Device Information (1) PART NUMBER PACKAGE BODY SIZE (NOM)
SN74HCS05PWR TSSOP (14) 5.00 mm × 4.40 mm SN74HCS05DR SOIC (14) 8.70 mm × 3.90 mm (1) For all available packages, see the orderable addendum at the end of the data sheet. Low Power Noise Rejection Supports Slow Inputs t e t e t e Input Voltage u g u g u g p lta p lta p lta In In In Waveforms Vo Vo Vo Input Voltage Time Time Standard e e g g t n lta lta CMOS Input rre t Vo t Vo u u u C tp t tp t ly u n u n p O O p Response rre rre u u Su C C Waveforms Input Voltage Time Time Schmitt-trigger e e g g t CMOS Input n lta lta rre t Vo t Vo u u u C tp t tp t ly u n u n Response p O O p rre rre u u Waveforms Su C C Input Voltage Time Time
Benefits of Schmitt-trigger Inputs
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications, Copyright © 2020 Texas Instruments Incorporated Submit Document Feedback 1 intellectual property matters and other important disclaimers. PRODUCTION DATA. Product Folder Links: SN74HCS05 Document Outline 1 Features 2 Applications 3 Description Table of Contents 4 Revision History 5 Pin Configuration and Functions Pin Functions 6 Specifications 6.1 Absolute Maximum Ratings 6.2 ESD Ratings 6.3 Recommended Operating Conditions 6.4 Thermal Information 6.5 Electrical Characteristics 6.6 Switching Characteristics 6.7 Operating Characteristics 6.8 Typical Characteristics 7 Parameter Measurement Information 8 Detailed Description 8.1 Overview 8.2 Functional Block Diagram 8.3 Feature Description 8.3.1 Open-Drain CMOS Outputs 8.3.2 CMOS Schmitt-Trigger Inputs 8.3.3 Clamp Diode Structure 8.4 Device Functional Modes 9 Application and Implementation 9.1 Application Information 9.2 Typical Application 9.2.1 Design Requirements 9.2.1.1 Power Considerations 9.2.1.2 Input Considerations 9.2.1.3 Output Considerations 9.2.2 Detailed Design Procedure 9.2.3 Application Curves 10 Power Supply Recommendations 11 Layout 11.1 Layout Guidelines 11.2 Layout Example 12 Device and Documentation Support 12.1 Documentation Support 12.1.1 Related Documentation 12.2 Related Links 12.3 Support Resources 12.4 Trademarks 12.5 Electrostatic Discharge Caution 12.6 Glossary 13 Mechanical, Packaging, and Orderable Information
