MIN1072M MinE-CAP
Bulk Capacitor Miniaturization and Inrush Management IC for Very High Power Density AC/DC Converters
Product Highlights
• Up to 50% volume reduction of input bulk capacitors (E-CAPs) CLV • Eliminates inrush NTC • Significantly reduces i2t stress on the input bridge rectifier and fuse • Partners with the InnoSwitch™ IC family for lowest component count CHV ultra-compact AC/DC converters
~ D VBOT VTOP L D V FWD SR BPS GND IS Advanced Protection / Safety Features MinE-CAP VOUT
• Integrated temperature sensing and hysteretic thermal shutdown
S BP S BPP InnoSwitch3-CP
• Input surge protection PI-9208-100720 • Pin open/short-circuit and E-CAP UV/OV fault reporting
Applications
Figure 1. Typical Application Schematic. • High power density universal input AC-DC converters • Applications with very wide input range (90 – 350+ VAC)
Description
180 170 The MinE-CAP™ IC dramatical y shrinks the size of input bulk capacitors 160 without compromising output ripple, operating efficiency or requiring -9209-110220 150 PI redesign of the transformer. When compared to traditional techniques 140 130 such as very high switching frequency operation, MinE-CAP achieves µ
